U500
- Unique dual-function graphics cards holder
- 480mm radiator support
- Equipped with 120mm x5 PWM fans
- The rear fan features a digital fan speed display
- Supporting up to 420mm graphics cards
- Lighting fast Type-C
Aesthetics Meet High Performance
The U500 is a workstation-grade case that combines a sleek, minimalist design with powerful performance. Whether you’re overclocking or running demanding applications, it delivers stable and efficient cooling for maximum system reliability.
Unique Dual-Function Graphics Cards Holder
A dual-purpose design that adapts to different GPU sizes, securely locks the card in place to prevent sagging or slipping, while also serving as a dual graphics card holder for enhanced stability.
Unleash the Graphics Cards Power
The U500 is engineered to handle the intense workloads and computing demands of high-performance workstations.
High Capacity and Ultimate Compatibility
With its spacious interior, the U500 is designed to support a wide range of motherboards, including E-ATX, ATX, M-ATX, and Mini-ITX. It also accommodates dual high-end graphics cards, making it the perfect choice for powerful, versatile builds.
Precision Cooling Redefined
The U500 boasts a digital fan speed display for real-time monitoring and dynamic speed adjustment, delivering reliable performance even under demanding workloads. It comes equipped with five 120mm PWM fans, ensuring efficient cooling performance.
STORAGE
SSD x6 / HDD x4
Ultimate Cooling Power
Experience unmatched cooling efficiency with our cutting-edge PC case design. This case ensures optimal airflow to keep your system running at peak performance.
Unleash Extreme Cooling: 480mm Radiator Support
Designed for ultimate thermal performance, this PC case supports a 480mm radiator, offering superior heat dissipation for high-performance builds.
USB PORT
Type-C / USB3.0 x 2
PSU
240mm PSU
Specifications
| Model Name | U500-B |
|---|---|
| Type | Workstation |
| Color | Black |
| Materials | 0.8mm SPCC |
| Weight | 10.6KG |
| Dimension DxWxH (mm) / (inch) | 451x258x568mm |
| Maximum CPU Cooler Height | 180mm |
| VGA Card Length | 420mm with Graphics Card Holder(Fixed bracket design) |
| Expansion Slots | 9 (Support vertical graphics card insertion) |
| MotherBoard Support | EEB, CEB, E-ATX,ATX, M-ATX, Mini-ITX |
| External I/O port | USB3.0 x 2, Type-C |
| Power Supply Type | 250mm ATX |
| 3.5“ HDD | 4(share with SSD) |
| 2.5" SSD | 6 |
| Fan Including(Pre-installed) | Front: 120mm PWM x 4 Rear: 120mm PWM fan x 1(Digital fan speed display) |
| Fan&Water Cooler Support | Front: 120mm x 4 or 140mm x 3 or 420/480mm Radiator Top: 120/140mm x 3 or 360mm Radiator Bottom: 120mm x 3 Rear: 120/140mm x1 |
| Max Radiator Support | 480mm |
| Container Information | CBM: 40" without pallet: 600PCS |
| EAN/UPC | EAN: 4711498480859 UPC: 845685015457 |
Download
U500-User manual .pdf
